Kaifeng Electron
Kaifeng Electron
凱峰電子
Barrier Terminal Block TB-450-16.7mm
Material：M5.0 Steel，Ni platedTerminal：Brass，1.0t Ni platedHousing: PCElectricalULIECRated voltage300V 750V Rated current30A41AInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range22-10AWG 6.0mm2MechanlicalTemp.rang-40℃～+105℃ Torque2.0N.m 17.54Lb.in
Color
  • Kaifeng Electron
Line count
  • 02P
  • 03P
  • 04P
  • 05P
  • 06P
  • 07P
  • 08P
  • 09P
  • 10P
  • 11P
  • 12P
  • 13P
  • 14P
  • 15P
  • 16P
  • 17P
  • 18P
  • 19P
  • 20P
  • 21P
  • 22P
  • 23P
  • 24P
Product Drawing Material Electrical Mechanical Packaging
Product Drawing
Kaifeng Electron
Material
  • Screws
    M5.0 Steel Zinc plated
  • Terminal
    Brass，1.0t Plated
  • Housing
    PC
Electrical
  • Rated voltage
    300V UL丨 750 lEC
  • Rated current
    30A UL丨 41A lEC
  • Insulation resistance
    500MΩ\DC500V
  • Withstanding voltage
    AC2000V\1Min
  • Wire range
    22-10AWG 6.0mm2
Mechanical
  • Wire range
    LOW-40℃ 丨TOP+105℃
  • Torque
    2.0N.m 17.54Lb.in
Packaging
  • Net Weight
    xg
  • SPQ
    12pcs
  • Packaging
    Ziploc
  • MOQ
    12pcs
  • Packaging
    Box45cm*28cm*27cm
